High-Performance Motion Control for Industrial Automation.
The 86AM45ED Closed Loop Stepper Motor is a powerful and reliable motion control solution designed for demanding industrial automation applications. Built with advanced closed-loop technology, this motor combines the precision of a stepper motor with real-time feedback control, ensuring superior accuracy, high torque output, and smooth operation. With its 86mm NEMA 34 frame size, 4.5 N.m holding torque, and 14mm shaft diameter, the 86AM45ED is ideal for CNC machines, robotics, packaging systems, and other high-performance automation equipment.
Closed-loop technology continuously monitors motor position and automatically corrects deviations, eliminating missed steps and improving overall system efficiency. This results in enhanced productivity, reduced downtime, and longer equipment life.
Key Features
86mm NEMA 34 Frame Size
The NEMA 34 frame provides a robust and durable construction suitable for heavy-duty industrial applications requiring high torque and reliable operation.
4.5 N.m Holding Torque
Delivers strong holding and driving force for demanding motion control tasks, ensuring consistent performance even under varying loads.
14mm Shaft Diameter
The sturdy 14mm shaft offers excellent mechanical strength and compatibility with industrial couplings, gearboxes, and drive systems.
Closed Loop Technology
Integrated encoder feedback continuously monitors motor position, allowing automatic correction of position errors and preventing missed steps.
High Positioning Accuracy
Achieves precise movement and repeatability, making it suitable for applications where accuracy is critical.
Reduced Heat Generation
Operates more efficiently than traditional open-loop stepper motors, resulting in lower heat buildup and improved system reliability.
Low Noise Operation
Provides smoother motion and quieter performance, enhancing the working environment and equipment longevity.
No Lost Steps
Real-time feedback ensures accurate positioning even during sudden load changes or rapid acceleration and deceleration.
Ideal Applications
CNC Machines
Provides accurate positioning and reliable motion control for milling, drilling, engraving, and cutting operations.
Pick and Place Systems
Ensures fast and precise movement required in assembly and material handling applications.
Robotics
Delivers smooth motion control for robotic arms, automated handling systems, and collaborative robots.
Packaging Equipment
Maintains accurate product positioning and synchronization in packaging and labeling lines.
Automation Machinery
Suitable for a wide range of industrial automation equipment requiring dependable motion control.
Why Choose the 86AM45ED Closed Loop Stepper Motor?
- Real-time encoder feedback
- Eliminates missed steps
- High torque performance
- Improved positioning accuracy
- Reduced motor heating
- Low vibration and noise
- Increased operational efficiency
